Description
Complete 3D Machine Control for Your Dozer – Install It Yourself and Save – Cab or Blade Mount.
Get professional-grade 3D dozer blade guidance with the Hemisphere VR1000 GradeMetrix system. Our complete self-install kit includes everything you need for a successful installation, plus comprehensive support to ensure you get it right the first time.
Complete VR1000 3D Kit Includes:
🎯 Precision Sensor Package
- Frame sensor – chassis reference and stability
- Blade lift sensor – accurate blade height measurement
- Blade tilt sensor – precise cross-slope positioning
- Blade pitch sensor – cutting edge angle control (optional)
- All mounting brackets – welded or magnetic options available
- Professional sensor cables – weatherproof M12 connections
📡 Advanced GNSS Positioning
- Dual GNSS antennas – heading and positioning accuracy
- VR1000 receiver – multi-constellation satellite tracking
- Integrated UHF radio – RTK correction data reception
- Single cable connection to IronTwo display for simplified installation
- Antenna cables with proper separation for optimal performance
- Universal antenna brackets – Options
💻 IronTwo Display System
- 10.1″ IronTwo touchscreen
- User-friendly interface – intuitive operation for all skill levels
- GradeMetrix software pre-loaded with Australian coordinate systems
- RAM mounting system – secure, adjustable cab installation
- Touch screen operation – works with gloves in all conditions
🔌 Complete Connection System
- Multiport connection box – central system hub
- Power cables – 12V/24V dozer connection
- CAN bus communication – reliable sensor networking
- Weatherproof connectors throughout system
- Cable management accessories – professional installation appearance
Why Choose VR1000 3D Self Install?
💰 Significant Cost Savings
- No waiting for installation appointments – install on your schedule
- Learn your system inside out – better troubleshooting capability
- Flexible timing – install during machine downtime
- Online Training – Full training and support
🛠️ Complete Installation Support
- Comprehensive installation guides – step-by-step with photos
- Video tutorials available for complex procedures
- Technical support hotline – expert help when you need it
- Red Edge Resources backing – Australian support you can trust
📈 Professional Results
- Centimeter-level accuracy – same precision as professional installs
- Full 3D guidance – grade, slope, and design file capability
- Real-time cut/fill display – instant productivity feedback
- Design file compatibility – works with all major CAD formats
VR1000 GradeMetrix 3D Capabilities
🏗️ Complete 3D Guidance
- Design file following – automatic grade and slope guidance
- Cut and fill display – real-time depth and volume information
- Multiple reference options – laser, GNSS, or design file
- Blade edge tracking – precise cutting edge location
- Cross-slope control – automatic side-to-side blade positioning
📊 Advanced 2.5D Features
- 2.5D function – use guidance technology without complex 3D files
- Eliminates survey points – no local transformations needed
- Faster work cycles – dramatically improved ROI
- Simple grade establishment – perfect for coarse grading
- Material layering guidance – ideal for road construction
🎮 Operator-Friendly Interface
- Intuitive GradeMetrix operation – minimal learning curve
- Large, clear 10.1″ display – easy visibility in all conditions
- Simple mode switching – 1D/2D/3D operation as needed
- Customizable settings – adapt to operator preferences
Self Install Process Overview
Phase 1: Planning & Preparation (1-2 hours)
- Review installation guide and video tutorials
- Identify optimal sensor mounting locations on blade assembly
- Prepare tools and workspace
- Plan cable routing paths through dozer frame
Phase 2: Sensor Installation (4-5 hours)
- Mount sensors on frame and blade assembly
- Install mounting brackets (welded or magnetic)
- Route sensor cables with proper protection
- Connect sensor chain to multiport box
Phase 3: GNSS & Display Setup (2-3 hours)
- Install dual GNSS antennas with proper separation on ROPS
- Mount IronTwo display in operator cab
- Connect VR1000 receiver with single cable to display
- Install multiport connection box
Phase 4: System Configuration (1-2 hours)
- Power up system and verify connections
- Configure GNSS settings for Australian conditions
- Set up RTK correction source
- Test basic system functionality
Phase 5: Calibration & Testing (3-4 hours)
- Measure blade geometry and pivot points accurately
- Perform sensor calibration procedures
- Verify system accuracy with test points
- Complete operator training and handover
Total Installation Time: 10-14 hours
Installation Support Included
Comprehensive Documentation
- Detailed installation manual – step-by-step procedures
- Component identification guide – know every part
- Wiring diagrams – clear connection instructions
- Troubleshooting section – solve common issues
Tutorial Library
- Installation overview – complete process walkthrough
- Sensor mounting techniques – professional tips and tricks
- Calibration procedures – ensure accuracy from day one
- Software operation – maximize system capabilities
Expert Technical Support
- Installation hotline – 1300 769 359 during business hours
- Email support – detailed technical assistance
- Remote assistance – TeamViewer support when needed
- Follow-up service – ensure your success
What You Need to Provide
🔧 Basic Tools Required
- Standard hand tools (spanners, screwdrivers)
- Welding equipment (if using welded brackets)
- Measuring tape and level
- Basic electrical tools
⚡ Machine Requirements
- 12V or 24V electrical system
- Standard dozer configuration
- Access to operator cab for display mounting
- Clear sight lines for GNSS antennas on ROPS
System Specifications
Accuracy Performance:
- Horizontal: ±2cm typical with RTK corrections
- Vertical: ±3cm typical with RTK corrections
- Update Rate: 10Hz for smooth guidance
- Working Range: Limited only by RTK correction source
Environmental Ratings:
- IP67 rated sensors – fully weatherproof
- Operating Temperature: -30°C to +70°C
- Shock and Vibration: Heavy-duty construction rated
- EMC Compliance: Meets Australian standards
Investment and Value
Complete VR1000 3D Self Install Kit: $25,000
What This Includes:
- All hardware components listed above
- Comprehensive installation support
- 36-month manufacturer warranty
- Red Edge Resources technical backing
- Software updates and support
Optional Enhancements
📡 C631 Base Station
- Provides GNSS RTK corrections to your dozer
- Independent operation – no network dependency
- Extended range capability for large sites
- Professional base station accuracy
Why Red Edge Resources?
🏆 Australia’s VR1000 Specialists
- Authorized Hemisphere dealer with full technical support
- Installation training developers – we wrote the masterclass
- First VR500 GradeMetrix installation in Australia (2019)
- Over 60 Hemisphere installations completed
- Local Australian support – no overseas call centers
📞 Comprehensive Support Network
- Technical hotline during business hours
- Email support for detailed questions
- Remote assistance via TeamViewer
- Replacement parts readily available
Proven Track Record
Quality Where It Counts
- Zero damage returns – our installation quality speaks for itself
- Preventive maintenance programs available
- Priority support 6am to 6pm Monday to Saturday
- 12-month maintenance and managed services options
Get Your VR1000 3D Kit Today
📞 Call for Immediate Availability: 1300 769 359
Ready to Install? We Need to Know:
- Dozer make, model, and year
- Blade type (straight, angle, or U-blade)
- Hydraulic system specifications
- Installation timeline
- RTK correction source preference
Success Guarantee
We’re so confident in our self-install support that we guarantee your success. If you can’t get your VR1000 system operational following our guides and support, we’ll arrange professional installation at no additional charge.
Ready to save money while gaining the precision your projects demand?
Red Edge Resources VR1000 3D Self Install “Professional results, DIY savings, complete support”
Call 1300 769 359 – Your 3D dozer guidance solution is ready to ship
